1 / 12

Receiver assembly
2 / 12

Receiver assembly
3 / 12

Receiver assembly
4 / 12

Front view of flowline showing Transmitter and Receiver assembly
5 / 12

Transmitter assembly line
6 / 12

Transmitter assembly - First operation - Back electrode assembly
7 / 12

Transmitter assembly - Second operation - Assembly of back electrode to front electrode
8 / 12

Transmitter assembly - Third Opertion - Sealing, spinning, drying and assembling front guard and spring disc
9 / 12

Receiver manufacturer - First operation - Assembling pole pieces
10 / 12

Receiver manufacturer - Second operation - Assembling pole pieces to case
11 / 12

Receiver manufacturer - third operation - Connecting and grinding
12 / 12

Receiver manufacturer - Fourth opertion - Sealing, staking and magnetising
