ERICSSON
TELEPHONE No. AC 200



Magneto table telephone


(Old catalogue No. 385)

Micro-telephone RE 2002 (Old Cat. No. 520) resting on a cradle switch, with cord RS 7021 (No. 2252), flexible cable RS 9610 (No. 2068) and terminal block with disc protector.

Generator, 2-magnet, which will ring satisfactorily through the ringer and a line resistance of 12000 - 15000 ohms.

This generator is fitted with 2 cranks.

The magnets also form the legs of the telephone.

Ringer. Resistance of coils: 300 Ohms.

Weight: 5.3 kg.

In both the 1905 and 1912 Ericsson Telephone Catalogue
