CONNECTOR No. 101/1A and 101/2A
|
|||||||
| The Connector No. 101 is used to connect portable
apparatus to fixed cable. The connector comprises of a
plastic box with a frame for fixing plastic mouldings. The
plastic mouldings are used to make a connector plug on the end of
the fixed cable. The portable apparatus would then plug into
this connector plug. The Connectors comes in two variants. The 1A has two plastic mouldings (white and yellow) and the 2A has three plastic mouldings. Both had bags of gold pins to connect to the end of the fixed cable. These pins were attached using special crimping pliers. The Connector No. 101/1A was used on PMBX No. 2/3. The Connector No. 101/2B was used on PMBX No. 2/4.  Connector 101 cover  Connector 101/1A showing the two plastic mouldings and gold pins |
|||||||
